Cloud Connector (2nd Gen)

image 13.jpg

The Cloud Connector uses a cellular or ethernet connection to relay data from wireless sensors that communicate using the SecureDataShot protocol to the DT Cloud infrastructure. Data from the cloud can be viewed directly in DT Studio or integrated into other services using REST APIs and webhooks.

The Cloud Connector is offered in two versions: Cellular/Ethernet version and Ethernet-Only version. Each version has two variants, EU and US, and is tailored to meet distinct regional certifications, compliances, and wireless communication requirements.

Datasheets

  Datasheet Cloud Connector (2nd Gen) EU/US

Specifications

Operating conditions
Temperature 0 to 50 °C | 32 - 120°F
Humidity 10 to 90% RH (non-condensing)
Wireless communication
 EU / US 868 MHz SRD band / 915 MHz ISM band, SecureDataShot
Range
Indoor See sensor specifications for more details.
Power
Power supply 5V DC @ 2A
Power Consumption Average < 3W¹
Power over Ethernet (PoE) Not by default - PoE splitter is needed
Cellular communication
Transmit Power EU/US Cat 1 LTE FDD / Cat M1 LTE FDD
Other
Size and weight 153 x 114 x 30 mm, 200 g | 6 x 4.5 x 1.2 inches, 7 oz
Construction Polycarbonate (PC), IP20
Data Backfill No

¹ The average power consumption of the Cloud Connector will vary depending on whether Ethernet or Cellular mode is used.
