Cloud Connector EU 4G

PN 101505


The Cloud Connector EU 4G connects the whole range of SecureDataShot™ enabled Sensors to the Cloud through a Power-over-Ethernet or 4G/3G/2G cellular connection.

There is no need for configuration during installation. The Cloud Connector will transparently relay traffic between all Sensors in range and the Cloud without the need for any user configuration or intervention.


Specifications

Operating Conditions
Temperature 0 to 45 °C
Humidity 10 to 90% relative humidity, non-condensing
Other
Ingress protection IP20
Dimensions 130 x 65 x 40 mm
Weight 200 g
Power supply Power-over-Ethernet (PoE) - 36-57 V - IEEE802.3at Type 1
Power consumption Average < 5 W (3 W typical), peak < 19 W (< 5 ms)
Certification and compliance CE, WEEE
Interfaces 100Base-T - RJ-45

See datasheet for detailed specifications.

Documents

 Datasheet Cloud Connector EU 4G 101505
 Safety and Use Leaflet
 Declaration of Conformity Cloud Connector EU 4G 101505
