The Wireless Counting Tactile Touch Sensor detects when the sensor is pressed and gives audible and tactile feedback to the user. A press will increment an internal counter, and the cloud server is updated with the count number at periodic intervals.
A wireless message will be sent to nearby Cloud Connectors (gateways) at a predetermined Heartbeat Interval (HBI) via the SecureDataShot™ protocol. Cloud Connectors relay sensor data to the cloud via cellular or ethernet connectivity. From the cloud, the data can be integrated into other services using REST APIs and webhooks or viewed directly in DT Studio.
An immediate message is transmitted if the sensor is pressed and held for approximately 4 seconds, allowing real-time sensor testing.
The Wireless Counting Tactile Touch Sensor uses HBI to transmit a message notifying the system that it is present and operational, which can be set to 15 min, 30 min, 45 min, or 60 min.
This sensor comes in two versions: EU (Product No. 101677) and US (Product No. 101728), each tailored to meet distinct regional certifications, compliances, and wireless communication requirements.
Datasheets
Datasheet Wireless Counting Tactile Touch Sensor EU 101677 (No longer available for purchase)
Datasheet Wireless Counting Tactile Touch Sensor US 101728 (No longer available for purchase)
Specifications
| Operating conditions | |
| Temperature | -40 to 85 °C / -40 to 185 °F |
| Humidity at 25 °C / 77 °F | 0 to 100% RH (non-condensing) |
| Wireless communication | |
| EU / US | 868 MHz ISM band / 915 MHz ISM band, SecureDataShot™ |
| Range | |
| Indoor | up to 40 m | 131 ft |
| Battery | |
| Battery type | Lithium |
| Replaceable battery | No |
| Lifetime | Up to 15 years in the default configuration and standard environment |
| Other | |
| Size and weight | 26 x 26 x 5.9 mm, 5.0 g / 1 x 1 x 0.23 in, 0.18 oz |
| Construction | ABS |
| Data Backfill | No |
